Pipe Plug, Petestop®, Inflatable Line Stop, Hp, 3" Dia
$1,790.00
9 In stock
SKU
129-003-HP
Pipe Plug, Petestop®, Inflatable Line Stop, Hp, 3" Dia
| Country of Origin | USA |
|---|---|
| Dia. Deflated | 2.875 (73mm) |
| Dia. Hot Tap Hole, Min | 2.875 (73mm) |
| Dia. Max | 3" (76mm) |
| Length Deflated | 9" (229mm) |
| Length, Cylinder Contact | 6" (152mm) |
| Length, Overall, Inflated, IN | 7.5 " (191mm) |
| Material, Hardware | Aluminum and Plated Carbon Steel |
| Material, Outer Ply | Ballistic Nylon Reinforced Urethane |
| Port Location, Infl. | Centered on Diameter |
| Port, Inflation | .25" MNPT With 1" Ram Adapter |
| Pressure Pipeline Max Head | 100 psi (6.89 bar)/230.7 ft (70.3 m) |
| Pressure, Inflation Max | 200 psi (13.79 bar) |
| Sage Subcategory Number | W129 |
| Shipping Wt. | 4 Lb (1.81 Kg) |
| Temperature Max. Service F | 225 F (107.22 C) |
